HOOK-UP WIRE,1 CONDUCTORS,18 AWG,600 V by Alpha Wire
Call For Price
- Part Number: 30751000WE
- UPC:
- Availability:
Quantity:
Add To Cart
Add To Estimate
Add To Wishlist
Compare Item
Product Variations (13)
Product Overview
Info & Guides
Alpha Wire 30751000WE Hook-Up Wire, 1 Conductors, 18 AWG, Stranded Tinned Copper, 16/30 Strands, 0.111 IN Outside Diameter, 600 V, Resistance: 7.1 OHM/1000 FT At 20 DEG C, -40 To 105 DEG C, PVC Insulation, White, 1000 FT Length, 0.032 IN Insulation Thickness, 0.047 IN Conductor Diameter, 1.11 IN Bend Radius, 12.6 LB Pull Tension, 0.07 UH/FT Inductance, CA Prop 65, CE, CSA TEW 105, UL AWM 1015, UL MTW CA Prop 65, CE - CE Conformance, CSA TEW 105, UL AWM 1015, UL MTW
Specifications
Details
Electrical Category:
Wire And Cable
Electrical Subcategory:
Electrical Cable
Electrical Subtype:
Building Cable
Color:
White
Length:
1000
Voltage Rating:
600
Brand Name:
Alpha Wire
Conductor Material:
Stranded Tinned Copper
Conductor Size:
18
Country Of Origin:
USA
Insulation Material:
PVC
Number Of Conductors:
1
Order Minimum:
1.000 RE
Order Multiple:
1.000 RE
Outside Diameter:
0.111
Resistance:
7.1 OHM/1000 FT At 20 DEG C
RoHS Compliance:
Contact Manufacturer
Special Features:
The broad range of hook-up wire from Alpha means you will find the product exactly suited to your application - whether it’s as straightforward as a control cabinet in a protected environment or as specialized as a machine tool on the factory floor, a hi
Strands:
16/30
Temperature Rating:
-40 To 105
Type:
Hook-Up Wire
UNSPSC:
26121614
Manufactured By:
Alpha Wire
