Fire Alarm Cable,NO Of Conductors: 4 by IDEA Honeywell
Call For Price
- Part Number: 43121004
- UPC: 00619172019651
- Availability:
Quantity:
Add To Cart
Add To Estimate
Add To Wishlist
Compare Item
Product Overview
Honeywell Cable 43121004 Fire Alarm Cable, Number Of Conductors: 4, Conductor Size: 16 AWG, Solid Bare Copper, Outside Diameter: 0.184 IN, 300 V, Resistance: 4.15 OHM/100 MR At 20 DEG C, -20 To 75 DEG C, Insulation Material: Polypropylene, Jacket Material: PVC, Shield: Unshielded, Red, Insulation: Black/Red/Yellow/Green, 1000 FT Length, Insulation Thickness : 0.006 IN, Insulation Diameter: 1/16 IN, Lay Length: 2-1/2 IN, Jacket Thickness: 1/64 IN, Impedance: 75 OHM, Capacitance: 20 PFD/FT, UL Standards 13, NEC Article 725 Type CL2R And UL Standards 1424, NEC Article 760 Type FPLR; Flame Rating: UL 1666 Riser, C(UL) FT4, RoHS Compliant
Specifications
Details
Electrical Category:
Wire And Cable
Electrical Subcategory:
Electrical Cable
Electrical Subtype:
Control Cable
Color:
Red, Insulation: Black/Red/Yellow/Green
Length:
1000
Voltage Rating:
300
Brand Name:
Honeywell
Conductor Material:
Solid Bare Copper
Conductor Size:
16
Country Of Origin:
US
Insulation Material:
Polypropylene
Jacket Material:
PVC
Number Of Conductors:
4
Order Minimum:
1.000 RE
Order Multiple:
1.000 RE
Outside Diameter:
0.184
Resistance:
4.15 OHM/100 MR At 20 DEG C
RoHS Compliance:
Yes
Shield:
Unshielded
Sub Brand:
Honeywell Cable
Temperature Rating:
-20 To 75
Type:
Fire Alarm Cable
UNSPSC:
26121603
Weight:
42.000 L
Manufactured By:
IDEA Honeywell
