Loop Power Supply,120VAC,(98056301) by Time Mark
$
140
00
/ EA
/ 1 EA
- Part Number: 650-120-24
- UPC: 00662917004467
- Availability:
Quantity:
Add To Cart
Add To Estimate
Add To Wishlist
Compare Item
Product Variations (2)
Product Overview
The Model 650 Loop Power Supply provides DC power for instrumentation control modules. Each option provides three output selections. For example the Model 650-240-24 has output options of 24 VDC regulated, 32 VDC unregulated, and 60 Hz pulse at 46 peak volts (See datasheet for all output selections). All outputs for the Model 650 are floating, electrically isolated from ground. A power status indicator (LED) is located on the top of the unit. The POWER LED comes ON when power is applied. Applications for this device include two-wire current loop transducers, such as pressure, voltage or current. The Model 650 may also be used with alarm indicators, meters and timers.
Specifications
Details
Electrical Category:
Electrical Distribution Equipment
Electrical Subcategory:
General Power Distribution
Application:
Provides DC power for two-wire loop transducers (pressure, voltage or current), alarm indicators, meters and timers.
Brand Name:
Time Mark
Country Of Origin:
USA
Enclosure:
ABS Plastic
Frequency Rating:
60 Hz
Height:
4
Length:
1.95
Line Drawing Link:
Mounting:
8-Pin
Order Minimum:
1.000 EA
Order Multiple:
1.000 EA
RoHS Compliance:
No
Spec Sheet:
Special Features:
Input 120VAC, Output 24VDC regulated or 32VDC unregulated, 60Hz pulse at 46 peak volts, All outputs floating and electrically isolated from ground, 5 yr warranty.
Stock Type:
Shelf Stock
Type:
Loop Power Supply
UNSPSC:
39121004
Voltage Rating:
120 VAC
Weight:
9.500 O
Width:
1.95
Manufactured By:
Time Mark
